How to create timeline chart in SSRS report

Timeline chart can be very helpful to present what is happening during a specific time frame, enabling a clear visualization of all running background jobs. In SQL Server Reporting Services (SSRS), there is no direct control available for creating a time line chart. For example, if we have a SharePoint list that stores seminars going to happen this year, we can display this information using a timeline chart in SSRS report.

There can be multiple approaches to create a timeline chart. Here I am sharing the approach that is very easy to use.
We will be creating an SSRS report for Project Server data. As the project will have multiple milestones, so we can create a timeline chart that will display all milestones between project start and finish date.

Below is a step by step procedure to create the chart:

1. Create a report server project and a new Report “Timeline.rdl” as shown below.

2. Create connection to an instance of SQL Server within the report, and create a new Data Source.

3. Create a store procedure that will retrieve milestones from Project Server for a selected project.

• Have Project Name as filter
• To show milestone in different levels in timeline chart, apply logic for even/odd row based on row number. All the records in an even row will be displayed at one level and odd rows will be displayed in the other level in timeline chart through below query:

Case MilestoneName when ‘Start’  then ‘0’ when ‘End’ then ‘0’   else   ROW_NUMBER() over(order by MilestoneDate)%2 + 2  end as evenodd

In the above query, MilestoneDate represents TaskStartDate of milestone.

Output of this store procedure will be as follows:

MilestoneDate for Start and End MilestoneName represents “ProjectStartDate and ProjectFinishDate”

Now we are ready to create the chart.

1. Go to report design and right click on report area. Select Insert -> Chart




2. Select Category Groups as MilestoneDate and Values as Sum(evenOdd)




    Modify the Category group Label to show the date in “dd/mm/yyyy” using expression

   =Microsoft.VisualBasic.Strings.format(Fields!MilestoneDate.Value, “dd/MM/yyyy”)

3. Remove Chart Title, Axis Title, Legend
4. Enable Show Data Label in chart and modify the series label property to show Milestone Name
5. Modify the Horizontal Axis property Major Tick Marks






6. Modify horizontal axis property Axis Type, and disable side margins.

.

7. Modify horizontal axis property Line and make the Label Font bold.



8. Now select the Bar and go to the property window by pressing F4 and set properties as shown below:



9. Hide vertical axis and run the chart report, timeline chart will be displayed as shown below:

Conclusion:

This timeline chart can be exported in PDF and shared across the team.  Similar approach can be used to represent seminars within the years or any scenario.

Adding Custom Validations on JS Grid of MY Task Web Part in Project Server

In Project Server and SharePoint, we commonly use JS Grid control to display the tabular data in grid view. If you are using Project Server, then you must have seen that JS Grid is used on most of the out of the box available web parts. JS Grid also provides flexibility to carry out customization using its available APIs.

In one of the projects, there was a requirement to validate actual start date of the assignments of logged in user for My Task Web part. This implementation called for a custom solution.

Here’s a solution in which we have to validate if task Actual start date is null i.e. task not yet started, then Task Start Date must be later than or equal to current date.  If the validation rule fails, then we need to highlight those task rows.

The implementation steps for the solution are as follows:

1. Create a SharePoint page and add My Task Web Part on it.



2. To carry out custom validation on the JS Grid, we have to create a JavaScript file to add custom code, upload it on a SharePoint document library and add it on the SharePoint page created above using a content editor web part.
3. Now, let’s take a look at various JS grid methods used.

a. Get the instance of MY Task Grid

Each of the JS Grid Instance available out of the box has its predefined name.  When My Task Web part is added on a page, we get the component name as “MyTasksComponent” and we can use below code to get its instance on the page:

_grid = MyTasksComponent.get_GridSatellite().GetJsGridControlInstance();

b. Get the list of all Records of My Task Grid

To apply validation rule when page loads, we have to retrieve all JS Grid records using below code:

 allRecords = MyTasksComponent.get_GridSatellite().get_tableCache().GetRecords(ranges).records[0]

The rangesvariable contain the start and end value to fetch the records.

 ranges = [{pos: 0,
count:             MyTasksComponent.get_GridSatellite().get_tableCache().GetRecordCount()}];

MyTasksComponent.get_GridSatellite().get_tableCache().GetRecordCount() gives the count of total records in the grid.

c. Set the indicator for error on JS Grid row

_grid.SetRowError(allRecords[index].recordKey, “Custom Validation Message”);

After loading sp.js file on page, the custom JavaScript code runs which parse all MY Task JS grid and check Task Start date and Actual Start date value and highlight all the rows which fails the validation rule.

Let’s say the current date is 31 Jan 2016, then you can see that there are two tasks which are not yet started i.e. Actual start date is null and Task Start date has passed out as highlighted.

When you click on the indicator then the custom messages will be visible.

      The complete JavaScript code is here.

    /// <reference name=”MicrosoftAjax.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/Utility.debug.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/WebMethodManager.debug.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/shell.debug.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/TimesheetSatellite.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/RemoteTextConv.debug.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/ProjectFramework.debug.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/GridSatellite.debug.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/projectserverscripts.debug.js”/>

    /// <reference path=”~/_layouts/inc/pwa/library/pagepropertymgr.debug.js”/>

    /// <reference path=”~/_layouts/SP.core.debug.js”/>

    /// <reference path=”~/_layouts/JsGrid.debug.js”/>

    /// <reference path=”~/_layouts/JsGrid.Gantt.debug.js”/>

ExecuteOrDelayUntilScriptLoaded(TaskGridLoad, “sp.js”);

function TaskGridLoad() {

    try {

        if (typeof(MyTasksComponent) === “undefined”) {

            return;

        }

        if (window.PJ == null || MyTasksComponent == null) {

            return;

        } else {

            _grid = MyTasksComponent.get_GridSatellite().GetJsGridControlInstance();

            var ranges = [{

                pos: 0,

                count: MyTasksComponent.get_GridSatellite().get_tableCache().GetRecordCount()

            }];

            var allRecords = MyTasksComponent.get_GridSatellite().get_tableCache().GetRecords(ranges).records[0];

            var today = new Date();

            var currentDate = new Date(today.getMonth() + 1 + “/” + today.getDate() + “/” + today.getFullYear());

            //Iterate through all records to check for the validation rule

            for (var index = 0; index < allRecords.length; index++) {

                var AssgnStartDate = allRecords[index].properties[“ASSN_START_DATE”].localizedValue

                var AssgnActualStartDate = allRecords[index].properties[“ASSN_ACT_START”].localizedValue

                 var assnStartDate = null;

                if (AssgnActualStartDate == null || AssgnActualStartDate == undefined) {

                    if (AssgnStartDate != null || AssgnStartDate != undefined) {

                        assnStartDate = new Date(AssgnStartDate);

                    }

                     if (assnStartDate < currentDate) {

                      _grid.SetRowError(allRecords[index].recordKey, “Start Date should be later or equal to current date”);

                    }

                }

            }

         }

    } catch (err) {

        alert (err.Message);

    }

}

 Conclusion:

As we have seen how to validate task rows with custom validation rules, similarly we can carry out any of our custom validations like validating actual and planned hours, or any enterprise task level custom fields value, on various events of JS grid.

Live Webinar: How to harness the power of agile and the structure of MS Project together to increase productivity

More and more companies are reaping the benefits of the agile methodology. Customers and users are more involved, teams are more engaged and solutions garner higher satisfaction from their customers. In many cases, this also means the adoption of a new tool for the project teams. Those adopting scrum are using PostIt Notes on their [Agile] Wall, Excel, Jira, Visual Studio Online or Rally to track the current and future sprint’s user stories or tasks.

The go-to project management tool has been MS Project/Project Online and is being used far and wide. Project managers are now preferring to use tools like Jira and TFS to track agile team’s activities. Visual Studio Online and Jira’s simple UI coupled with their activity planning and activity tracking features make it a favorite among team members. Project Online, Visual Studio Online and Jira each have their strengths and weaknesses.

Those organizations using Project Online for strong portfolio analysis and resource management are not able to find a competitive feature in Visual Studio Online or Jira. Conversely, Visual Studio Online (VSO) and Jira’s sprint planning and tracking is difficult to replicate in Project Online. The optimal solution would be to use Project Online during the project planning, and use VSO/Jira during work monitoring and controlling, and then again use Project Online to control schedule and cost.

Integration between Project Online and VSO or Jira allows team members to align their tool to their function and maximize efficiency. Project managers can create and manage project plans for prioritization by portfolio managers and utilization planning by resource managers. Selected project tasks in the form of a user story or activity, can be pushed to Jira or VSO project for agile poker/planning and execution. During the sprint, team members can enter new tasks or update task information, which can be pushed back to Project Online, allowing the Project Manager to control the schedule and cost.

Maximize your investments on project management tools with a simple integration and make the joy of eliminating double entry an increase in visibility and digital productivity – attend this webinar to learn how to harness the power of Agile methodology and tools with the structure of Microsoft Enterprise Project Management (EPM) on March 15, 2016  at 1400 hrs PST / 2200 hrs GMT

Create a custom task outcome in Project Server 2013

Workflows in SharePoint provide excellent ways to save effort, time, and cost by automating existing business functions. Here I am sharing the process of creating custom task outcomes in Project Server workflow.

SharePoint 2013 out of the box has two task outcomes – Approved and Rejected as shown below:

Let’s consider a use case – While creating a workflow in Project Server 2013, there is a requirement that if a project manager creates a project and submits it, it should go to the PMO for approval, and the PMO should get three options for approval- Forward to Manager, Approved, and Rejected as shown below:

Below are the steps to address this requirement through the custom task outcome functionality.

a)    Create a new task outcome column-

1. Go to PWA Site Settings – > Site columns









2. Click Create






3. Enter column name as Project Action Outcome and in the additional column settings add all the desired task outcomes. Click on OK.

b)    Create a new content type

1. Go to PWA Site Settings -> Site Content Type



2. Click Create



3. Create a custom content type as Project Action Content Type with below selections:



4. Click OK.
5. On the content types settings page, click Add from existing site column.
6. Add Project Action Outcome column to it.

c) Add a newly created content type to the workflow task list.

1. Open Project Server Workflow Task List
2. Go to List Settings -> Add Existing Content Type



3. Add Project Action Content Type

d) Update the wokflow-

1. Open/create Project Server workflow in SharePoint Designer 2013
2. Open the assign task property
3. Expand the Outcome options
4. Select the task content type as Project Action Content Type
5. The output will look like below:




6. Click Save and publish the workflow.
7. Now when you run the workflow and edit the task, you will see a newly created task outcome.



I have implemented this approach for Project Server workflow; the same approach can be used for any SharePoint workflow.
